135-150LM/W DMX LED Flood Light , IK09 Sport Court Lighting LED

1PC
MOQ
135-150LM/W DMX LED Flood Light , IK09 Sport Court Lighting LED
Features Gallery Product Description Request A Quote
Features
Specifications
LED Chip: Lumileds/Osram Chip
CRI: >70 (>80, >90 Available)
Efficiency: 135-150lm/W
CCT: 5000K (3000K, 4000K, 5700K Available)
BEAM ANGLE: 12°, 16°, 30°, 60°, Asy 25*130°,60*130°,40*130°
POWER FACTOR (Typ): ≥0.97
Material: Aluminium, Stainless Steel 304, PC
Color: Black/Grey
LED Driver: Inventronics Driver
Input Voltage: 100-227V/AC, 50-60Hz
IK Grade: IK09
IP Rating: IP66
Surge Protection: 10kV
Warranty: 5 Years
Highlight:

135LM/W DMX LED Flood Light

,

150LM/W DMX LED Flood Light

,

IK09 Sport Court Lighting LED

Basic Infomation
Place of Origin: China
Brand Name: LUXSUN
Certification: CE ENEC CB SAA
Model Number: LUX-SP2-1200/1800
Payment & Shipping Terms
Packaging Details: 889*215*860mm/919*215*1080mm
Delivery Time: 15-20days
Payment Terms: T/T, L/C
Supply Ability: 5000PCS/Month
Product Description

1200W 1800W OPSPORT DMX & DALI 2.0 SERIES LED SPORT LIGHTING, LED stadium lighting

Overview

OpSport DMX&DALI Dimmable Sports Field Light

OpSport DMX Dimmable Sports Field Light whether in large stadiums or amateur sports stadiums. Both provide an economical and effective way to bring professional-level lighting shows to your venue, which will inspire the enthusiasm of players and audiences and create a more memorable live atmosphere.




Main Features

• Ultra-high system efficiency of up to 150lm/W
• High quality Lumileds LED Chip and Inventronics Driver
• Long >10,2000 hours lifespan to L70
• Professionally Designed True Asymmetric Flat Optics
• Tough IP66 and IK09 construction
• Suitable for coastal areas (with optional 316 stainless steel bracket)
• High quality AkzoNobel anti-corrosion Powder-coating
135-150LM/W DMX LED Flood Light , IK09 Sport Court Lighting LED 0
135-150LM/W DMX LED Flood Light , IK09 Sport Court Lighting LED 1
135-150LM/W DMX LED Flood Light , IK09 Sport Court Lighting LED 2


135-150LM/W DMX LED Flood Light , IK09 Sport Court Lighting LED 3
135-150LM/W DMX LED Flood Light , IK09 Sport Court Lighting LED 4



Product Parameter

135-150LM/W DMX LED Flood Light , IK09 Sport Court Lighting LED 5




More Advantages

1.Wide selection of optics (Asymmetric: 25x130°/40x130° /60x130°/ & Symmetric:12°/16° /30° /60°)
High Uniformity and Eav [lx], 0° installation low windage

2.Spill control shields/specially designed high efficiency lens as standard.
Easier compliance to AS4282, low spill light<10lx, <12500dc

3.304 Stainless steel bracket and passivate treatment on the die-casting body, AkzoNobel Anti-corrosion powder coating, 10 years won't drop off
Can be used for seaside Environment

4.Drivers can be positioned at the base of the pole
Ease of maintenance

5.Tempered glass on the lens
Protect the lens, 10 years won't get yellow.

6.Fully dimmable with both wired and wireless protocols
Reduced operating costs and ability to choose what parts of the fields you illuminate

7.Cables concealed and protected by 304 SS prectection tube
No more issues with bird attack and UV damage

8. With wiring box, easy installation for electricians.
Reduced installation costs

9. Market-leading weight and sail area.
Easy retrofit of old style luminaires, and reduced install costs.

10.Patented heat sink design
Better heat dissipation in Australia’s harsh environment.

11.Full replacement warranty
Confidence that you are working with a company who stands behind their product

12.CE ROHS, ENEC, CB, SAA Certificates for all powers
