Durable Dimmable DMX LED Flood , Multiscene Sports Court Lighting

1PC
MOQ
Durable Dimmable DMX LED Flood , Multiscene Sports Court Lighting
Features Gallery Product Description Request A Quote
Features
Specifications
LED Chip: Lumileds/Osram Chip
CRI: >70 (>80, >90 Available)
Efficiency: 135-150lm/W
CCT: 5000K (3000K, 4000K, 5700K Available)
BEAM ANGLE: 12°, 16°, 30°, 60°, Asy 25*130°,60*130°,40*130°
POWER FACTOR (Typ): ≥0.97
Material: Aluminium, Stainless Steel 304, PC
Color: Black/Grey
LED Driver: Inventronics Driver
Input Voltage: 100-227V/AC, 50-60Hz
IK Grade: IK09
IP Rating: IP66
Surge Protection: 10kV
Warranty: 5 Years
Highlight:

Durable DMX LED Flood

,

Dimmable DMX LED Flood

,

Multiscene Sports Court Lighting

Basic Infomation
Place of Origin: China
Brand Name: LUXSUN
Certification: CE ENEC CB SAA
Model Number: LUX-SP2-1200/1800
Payment & Shipping Terms
Packaging Details: 889*215*860mm/919*215*1080mm
Delivery Time: 15-20days
Payment Terms: T/T, L/C
Supply Ability: 5000PCS/Month
Product Description

1200W 1800W OPSPORT DMX & DALI 2.0 SERIES LED SPORT LIGHTING, LED stadium lighting

Overview

OpSport DMX&DALI Dimmable Sports Field Light

The OpSPORT DMX & DALI 2.0 Series LED Sport Lighting is a state-of-the-art lighting solution for sports stadiums and arenas.
The fixtures can be remotely controlled with advanced lighting control protocols such as DMX and DALI 2.0 for precise lighting output and synchronization with other fixtures or events.
The wattage range of 1200W to 1800W indicates the power consumption of the lighting fixtures, with higher wattage resulting in brighter illumination.
LED technology is used in the fixtures, providing energy-efficient lighting with a longer lifespan than traditional lighting sources, reducing maintenance costs and environmental impact.
The OpSPORT series has an IP65 rating, making it suitable for use in various weather conditions, and comes with adjustable brackets and a variety of beam angles for flexibility in installation and lighting design.
Overall, the OpSPORT DMX & DALI 2.0 Series LED Sport Lighting is a reliable, energy-efficient, and versatile lighting solution for sports stadiums and arenas. Its advanced lighting control protocols and LED technology allow for precise control and high-quality illumination, while its durability and flexibility make it suitable for various applications.



More Advantages

1.Wide selection of optics (Asymmetric: 25x130°/40x130° /60x130°/ & Symmetric:12°/16° /30° /60°)
High Uniformity and Eav [lx], 0° installation low windage

2.Spill control shields/specially designed high efficiency lens as standard.
Easier compliance to AS4282, low spill light<10lx, <12500dc

3.304 Stainless steel bracket and passivate treatment on the die-casting body, AkzoNobel Anti-corrosion powder coating, 10 years won't drop off
Can be used for seaside Environment

4.Drivers can be positioned at the base of the pole
Ease of maintenance

5.Tempered glass on the lens
Protect the lens, 10 years won't get yellow.

6.Fully dimmable with both wired and wireless protocols
Reduced operating costs and ability to choose what parts of the fields you illuminate

7.Cables concealed and protected by 304 SS prectection tube
No more issues with bird attack and UV damage

8. With wiring box, easy installation for electricians.
Reduced installation costs

9. Market-leading weight and sail area.
Easy retrofit of old style luminaires, and reduced install costs.

10.Patented heat sink design
Better heat dissipation in Australia’s harsh environment.

11.Full replacement warranty
Confidence that you are working with a company who stands behind their product

12.CE ROHS, ENEC, CB, SAA Certificates for all powers






Main Features

• Ultra-high system efficiency of up to 150lm/W
• High quality Lumileds LED Chip and Inventronics Driver
• Long >10,2000 hours lifespan to L70
• Professionally Designed True Asymmetric Flat Optics
• Tough IP66 and IK09 construction
• Suitable for coastal areas (with optional 316 stainless steel bracket)
• High quality AkzoNobel anti-corrosion Powder-coating

Durable Dimmable DMX LED Flood , Multiscene Sports Court Lighting 0
Durable Dimmable DMX LED Flood , Multiscene Sports Court Lighting 1Durable Dimmable DMX LED Flood , Multiscene Sports Court Lighting 2Durable Dimmable DMX LED Flood , Multiscene Sports Court Lighting 3
Durable Dimmable DMX LED Flood , Multiscene Sports Court Lighting 4
Durable Dimmable DMX LED Flood , Multiscene Sports Court Lighting 5


Product Parameter

Durable Dimmable DMX LED Flood , Multiscene Sports Court Lighting 6






Production
Durable Dimmable DMX LED Flood , Multiscene Sports Court Lighting 7


Why Choose Us

why choose us-1

1. We use Dialux software to simulate the luminous effect, so as to make sure our proposals meet clients' requirements.

2. Our PMC department follows the production and we can report to you at any time about the production by photos and videos.

why choose us-2

3. We have IQC, IPQC, and OQC during the production, guarantee the products.

4. We have a large capacity and quickly finish the cargos in a short time with our experienced production team.


E40 E39 E27 25w-120w-detail-19

about us
Luxsun specializes in the research, design and production of LED floodlight, sport fields & stadium
light, high mast light, smart LED street light and LED high bay light since2014. all of products are
patented and the factory has been certificated by ISO9001:2015 &ISO14001:2015.

In the past eight years, Luxsun has gain great success and achievements. we have been awarded
more than 30patents, and our products have passed UL, FCC,ENEC,CB,SASO,SAA,CE and ROHS
certification. Including TM-21,LM-79, IP66,IK09, salt spray testing. our mainly markets are
exported to Europe,New Zealand, Australia,South Africa,South America, Middle-East etc.
