● Up to 151lm/w system efficacy
● Lumileds LED chips and Inventronics Driver package
● Separate driver box for heat dissipation, remote driver and driver on fitting installation optional
● 3000K, 4000K, 5000K and 5700K CCT
● 320W-2040W, 47,040lm–299,880lm Lumen Package
● 10kv/20kv surge protection optional.
● 1-10V/DMX, DALI dimming available,
● IP66 and IK09
● Full range of accessories available inc. laser scope for aiming and anti-glare hood shield.
| Part No. | LUX-SP-320/480/550 | LUX-SP-600/680 | LUX-SP-800/960/1100 | LUX-SP-1200/1360 | LUX-SP-1440/1650 | LUX-SP-1800/2040 |
| One Module | One module | Two modules | Two modules | Three modules | Three modules | |
| Power Range | 320W/480W/550W | 600W/680W | 800W/960W/1100W | 1200W/1360W | 1440W/1650W | 1800W/2040W |
| Input Voltage | AC100-277V 50-60Hz,PF>0.97 | |||||
| Angle | 12°/16°/30°/60°/25*130°/40*130°/60*130°/ | |||||
| Luminous Efficacy | Up to 150lm/W(±5%) | |||||
| CCT | 5000K(3000K,4000K,5700K, available) | |||||
| CRI | >70(>80,>90available) | |||||
| Dim options | 0-10v/Dali/DMX | |||||
| IP | 66 | |||||
| Operating temperature | -30°C to + 45°C | |||||
| LED Chips | Osram(12°/16°) & Lumileds 5050 (60°/25*130°/40*130°/60*130°/NB40) | |||||
| Driver | INVENTRONICS | |||||
| Color | BLACK & GREY | |||||
| Lifespan | >10,2000 hours lifespan to L70 | |||||
| Warranty | 5 years | |||||
